Specification Package AMDK packaging glass: mineral water
1.1 unit 4 Cupsealer Machine line
- Model DCM-4 m
- Capacity: 4000-4800 cups per hour
- Filling range: 50-250 ml
- Power: 2,
2 kW, 220 volt
- Dimensions: 1000 x 750 x 1650 mm
2. Belt Conveyor 1 Unit
- Material body: Plat MS
- System: conveyor belt
- Belt: Green 2 mm PVC
- Power: 0.5 HP, 380 Volt
3. Air Compressor Unit
- Made in: Taiwan
- Power: 3 HP
4.3 units multi media water filter stainless steel 20 "
- 3 unit stainless steel tubes 20 "SS 304
- Diameter: 45 cm
- Height: 165 cm
- Filter media: activated carbon, silica sand calgon bangka, manganese, Birm
5. the ozone generator 1 Unit of 20 grams per hour
6.3 units multi Housing stainless steel cartridges
- Material: Stainless steel
- Diameter: 25 cm
- Height: 90 cm
- Media: 15 pcs cartridges sedime
n
7.1 set of Lamps UVC
- Capacity: 60 GPM
- Chamber material: Stainless steel 304
8.2 Unit water tank polytheline
- Material: Polytheline
- Capacity: 5300 litres
- Diameter: 180 cm
- Height: 230 cm
9.3 unit stainless steel water tank
- Capacity: 3000 litres
- Material: St
ainless steel
- Diameter: 143 cm
- Height: 235 cm
10. the pump Unit 2 Stainless Steel
- Type: CNP CHLF 4-60
- Power: 750 Watt, 220 Volt
- Capacity: 4.2 m3/h
11. Plumbing
